MacroBin 48-FV

Features & Benefits

  • Impact-grade copolymer
  • Lightweight construction
  • FDA-approved materials
  • Ventilation slots
  • Nonporous surfaces
  • Rounded corners and smooth surfaces
  • Easy-to-sanitize
  • Splinter-resistant plastic

Partial List of Applications

  • Carrots
  • Garlic
  • Leafy Greens
  • Nuts
  • Potatoes

Full Specs

User Guide

CAD Files

Description

External Dimensions: 48 1/8” (L) x 48 1/8” (W) x 52 1/2” (H)
Internal Dimension: 44 7/8” (L) x 44 7/8” (W) x 46 ½” (H)
Load Capacity: 3,000 lbs
Volume Capacity: 94,000 cubic inches
Tare Weight: 180 lbs (+/- 5%)
Maximum Stack Weight: b. 15,925 lbs
Fork Lift Entry: Two-way
Accessories: MacroLid
Options:

External Dimensions: 1,222.4 mm (L) x 1,222.4 mm (W) x 1,333.5 mm (H)
Internal Dimension: 1,139.8 mm (L) x 1,139.8 mm (W) x 1,181.1 mm (H)
Load Capacity: 1,360.8 kg
Volume Capacity: 1,540.4 liters
Tare Weight: 81.6 kg (+/- 5%)
Maximum Stack Weight: b. 7,223.5 kg
Fork Lift Entry: Two-way
Accessories: MacroLid
Options:

Why Plastics?

Plastics improve product quality with better storage conditions and faster cooling for produce.

Why Reusable?

Reusable containers create tremendous environmental advantages by conserving materials and resources, reducing waste, and lowering packaging costs.

Notes:

All bins are ivory unless noted otherwise. Other bin colors are available at an additional cost. All bins are available with foil embossing at an additional cost. Dimensions assume tolerance of 1/8″ or 3 mm. Cubic capacities assume tolerance of 5% and tare weights assume tolerance of 4% unless noted otherwise. Maximum Stack Weight = (weight of bin contents + tare weight of bin) x number of bins in stack. Stack weights also influenced by length of storage and temperature; a = long term, ambient temperature; b = short term, ambient temperature (1 month or less); c = long term, cold storage (0º F to 35º F or -17ºC to 2º C). Ambient temperature approximately equal to 75º F (23.9º C) . Please contact Macro Plastics if storage temperature is below 0º F (-17º C).Please refer to the MacroBin User Guide for information on the safe transportation, stacking and handling of MacroBins. Click here for the latest version of the User Guide. Data is subject to change. Confirm with specification sheets.

Additional information

Dimensions 10 x 10 x 10 cm
Applications

Blueberries, Cherries, Cranberries
