ShuttleBin 330

Features & Benefits

  • Unique ten-point zipper latch system
  • Hundreds of ventilation slots
  • Lightweight design
  • FDA-approved materials
  • Splinter-resistant plastic
  • Nonporous surfaces
  • Easy-to-sanitize, smooth surfaces

Partial List of Applications

  • Agriculture
  • Avocados
  • Industrial
  • Melons
  • Seafood
  • Squash

Full Specs

User Guide

CAD Files

Description

External Dimensions: 40” (L) x 48” (W) x 33” (H)
Internal Dimension: 36 3/4” (L) x 44 3/4” (W) x 26 7/8” (H)
Load Capacity: 1,500 lbs
Volume Capacity: 47,000 cubic inches
Tare Weight: 105 pounds (no door)
106 pounds (1 door)
107 pounds (2 doors)
Maximum Stack Weight:  11,120 lbs (no door; long term, ambient temperature)
8,896 lbs (1 door; long term, ambient temperature)
6,000 lbs (2 doors; long term, ambient temperature)
Fork Lift Entry: Four-way
Accessories: MacroLid
Options: Tan only

External Dimensions: 1,016 mm (L) x 1,219.2 mm (W) x 838 mm (H)
Internal Dimension: 933.5 mm (L) x 1,136.7 mm (W) x 682.6 mm (H)
Load Capacity: 680.4 kg
Volume Capacity: 770.2 liters
Tare Weight: 49.0 kg (no door)
49.4 kg (1 door)
49.9 kg (2 doors)
Maximum Stack Weight: 5,043.9 kg (no door; long term, ambient temperature)
4,035.2 kg (1 door; long term, ambient temperature)
2,721.6 kg (2 doors; long term, ambient temperature)
Fork Lift Entry: Four-way
Accessories: MacroLid
Options: Tan only

Why Plastics?

Plastics improve product quality with better storage conditions and faster cooling for produce.

Why Reusable?

Reusable containers create tremendous environmental advantages by conserving materials and resources, reducing waste, and lowering packaging costs.

Notes:

All bins are ivory unless noted otherwise. Other bin colors are available at an additional cost. All bins are available with foil embossing at an additional cost. Dimensions assume tolerance of 1/8″ or 3 mm. Cubic capacities assume tolerance of 5% and tare weights assume tolerance of 4% unless noted otherwise. Maximum Stack Weight = (weight of bin contents + tare weight of bin) x number of bins in stack. Stack weights also influenced by length of storage and temperature; a = long term, ambient temperature; b = short term, ambient temperature (1 month or less); c = long term, cold storage (0º F to 35º F or -17ºC to 2º C). Ambient temperature approximately equal to 75º F (23.9º C) . Please contact Macro Plastics if storage temperature is below 0º F (-17º C).Please refer to the MacroBin User Guide for information on the safe transportation, stacking and handling of MacroBins. Click here for the latest version of the User Guide. Data is subject to change. Confirm with specification sheets.

Additional information

Dimensions 10 x 10 x 10 cm
Applications

Blueberries, Cherries, Cranberries
